Safety Light Curtain for Press Machine RFG

Product code: rikenoptech RFG

Vạn Năng Company
  • Click Download to download detailed product information
  • + PRODUCT DESCRIPTION:



    Safety Devices for Presses

    Safety Light Curtain for Press MachineRFG

    Robust safety light curtain with ultimate safety and functionality

    Features

    Manufacturing sites are now required to respond to globalization and flexible production. The RFG series is a Safety light curtain that realizes a significant improvement in work efficiency while thoroughly pursuing safety with a safety design and specifications that conforms to international standards, flexibly responds to various work contents, and is equipped with everything required of a safety light curtain. This series contributes to the construction of safety systems at any manufacturing site.

    • Fail-safe design meets global safety standards with the highest level of safety.
    • Cope with various usage environments with a rich lineup from finger detection to arm/leg detection.
    • The clear color indicators make it easy to check the status of the light curtain and to align the optical axis.
    • Achieves compact design and robustness with sealed structure and enhanced environmental resistance.
    • Environmentally resistant and robust structure that can be used even in harsh environments.

    Standard specifications 414Series/425Series/445Series

     RFG414-□□□RFG425-□□□RFG445-□□□
    Number of beams 15~199 8~124 6~38
    Protective height 140~1980mm 140~2460mm 200~1480mm
    Beam spacing 10mm 20mm 40mm
    Minimum object sensitivity
    (MOS)
    14mm 25mm 45mm
    Detection distance 0.3~10 m 0.3~20 m 0.3~20 m
